| Camera |
| Sensor |
1/2.7″ Progressive scan CMOS |
| Lens |
3.6mm (2.8mm lens optional) |
| Lens interface |
M12 |
| Focal Length & FOV |
2.8mm, horizontal FOV 108.3°, vertical FOV 59.9°, diagonal FOV 126.8°
3.6mm, horizontal FOV 89.3°, vertical FOV 47.9°, diagonal FOV 107° |
| Min. Illumination |
Color: 0.001Lux/F1.6, AGC ON, B/W: 0Lux(IR LED ON) |
| Electronic shutter |
1/5 s to 1/100,000 s |
| S/N Ratio |
≥ 52 dB |
| Day/ Night mode |
Auto, Day, Night, Custom |
| IR Distance |
30m(6x IR LED’s) |
| DWDR |
DWDR (off/low/middle/high) |
| IR Led Control |
Auto/Manual/Off |
| DNR |
Off/Low/Middle/High/Higher |
| Defog |
Off/Low/Middle/High |
| Mirror |
Off/ Horizontal Mirror/Vertical Mirror/180 degree flip |
| Image Setting |
Brightness, Contrast, Sharpness, Saturation, Chroma |
| General Events |
| Motion Detection |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
| Support full screen / area detection |
| Linkage setting support: upload mail/voice broadcast alarm/alarm light |
| Obstruction Alarm |
Support day arming/night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
| Support one detection area |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Privacy mask |
Support four areas setting |
| VCA |
| Area Intrusion |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
|
Support one detection area, and can draw a multi deformation detection area
(Detection area is consist of 6 points)
|
| Support video stream overlay detection frame |
| Support specified target type detection: human, vehicle (non-motor vehicle also can be detected) |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Line-crossing Detection |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
| Support one detection line, supports detection directions: A->B |
| Support video stream overlay detection frame |
|
Support specified target type detection: human, motor vehicle
(non-motor vehicle also can be detected)
|
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Wandering/ Loitering |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
|
Support one detection area, and can draw a multi deformation detection area
(Detection area is consist of 6 points)
|
| Support video stream overlay detection frame |
| Support wandering time setting(10~3600S) |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Absent Alarm |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
|
Support one detection area, and can draw a multi deformation detection area
(Detection area is consist of 6 points)
|
| Support video stream overlay detection frame |
| Support absent time setting (10-3600S) |
| Support at least 1-3 people on duty |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Vehicle Illegal Parking |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
|
Support one detection area, and can draw a multi deformation detection area
(Detection area is consist of 6 points)
|
| Support video stream overlay detection frame |
| Support illegal parking time setting (10-3600S) |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Vehicle Retrograding |
Support day arming /night arming mode; Support to configure the customized
arm time by week, with 4 time periods per day
|
|
Support one detection area, and can draw a multi deformation
detection area (Detection area is consist of 4 points)
|
| Support video stream overlay detection frame |
| Supports four detection directions, detection line support B->A direction |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm |
| Audio & Video Encoding |
| Video Encode Standard |
Smart H.265/H.265/H.264 |
| Encoding Feature |
Main stream: 4MP 2560×1440@25fps, 3MP 2304×1296@25fps,
2MP 1920×1080@25fps
|
| Sub stream: D1(720×576), VGA(640*480), Q720P(640*360), CIF(352*288)@25fps |
| Video Code Rate |
Fixed code rate, variable code rate (Main stream code：160Kbps-4000kbps) |
| Video Type |
Composited stream/video stream |
| Audio Standard |
G.711u /G.711A 64Kbps |
| Network Function |
| Protocol |
TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, RTP, IPv4, DDNS, NTP,
PPPOE, UPNP, SMTP, DNS, QoS
|
| Connection Protocol |
ONVIF, SLINK, HIK, TST |
| Preview Video Quantity |
5PCS |
| Security Mode |
Authorized user name and password, HTTPS with password,
AES connecting with password, RTSP verification
|
| Motion Detection |
Setup detection area, multi-level sensitivity available to setup |
| Obstruction Alarm |
Support 1 area setting |
| Privacy Mask |
Support 4 area privacy mask |
| Schedule Linkage |
Upload email/FTP upload picture, Arming time support day
arming/night arming/customized arming
|
| Anomaly Inspection |
Support network disconnection alarm, IP conflict alarm, illegal access alarm |
| Character Overlay(OSD) |
Support time OSD/Title OSD, multi-line OSD (two lines), Main stream font support 12-60pt,
sub stream font support 12-36pt
|
| Interface |
| Network Port |
RJ45 10M/100M network self-adjustable |
| TF Card slot |
Support, 512G in max. |
| Audio input |
Microphone built in |
| Audio output |
Speaker |
| Alarm input |
optional, 1ch |
| Alarm output |
optional, 1ch |
| General |
| Power Supply |
DC12V, 0.6A, max. 6W; PoE: 802.3af, max. 7W |
| Protection |
IP67, Metal |
| Size |
181.08(L)x70.17(W)x58.80(H)mm |
| Working Temperature |
-30°C ~ 60°C |
| Working Humidity |
0%~90% |
